Aluminum Foil Tape
The aluminum foil tape is made up of the aluminum foil substrate as well as the adhesive layer. This aluminum-based substrate has high reflectivity and conductivity and the adhesive layer makes sure that the tape will stick firmly to a variety of surfaces. It is also waterproof as well as shock-proof and insulation properties. Aluminum foil tape is used for many applications, such as building insulation as well as shielding and heat conduction of electronic components such as sound insulation, heat insulation in automotive manufacturing, etc.
The aluminum foil tape from Lanren is available in two varieties that are Industrial-Grade and General Purpose.
Specification of Aluminum Foil Tape
| Property | Description |
| Alloy | 1100, 1145, 1235, 3003, 8011 |
| Thickness of liner | 2.56 mils/0.065mm |
| Total thickness | 3.54 mils/0.09mm |
| Width | As required, common are 48mm, 50mm, 60mm, 72mm |
| Length | Standard rolls or customized |
| Tensile Strength | 19.99 lbs/in,35 N/cm |
| Elongation up tp | 10% |
| Service Temperature Range | -40°to 320°F/-40°C to 160°C |
| Type of adhesive | acrylic |
| Color | Silver |
| Hand tearability | good |
| Backing appearance (visual) | reflective |
| Water resistance | very good |
| Operation temperature from | |
| Standard | ISO SGS ASTM |
Types of Aluminum Foil Tape
Lanren aluminum foil tape is available in 2 types: General Purpose and Industrial-Grade.
General Purpose
- Construction: Typically made from an aluminum foil that has been softly dead coated with an acrylic solvent.
- Properties: Offers good adhesion and heat reflectivity, as well as flexibility, and resistance to moisture.
- Applications: Suitable for a broad range of general-purpose applications including HVAC sealing, repair of ductwork or vapor barriers, as well as the use of masking when electroplating or painting.
Industrial-Grade
- Construction: Often made from more robust, stronger aluminum foil and an aggressive adhesive.
- Properties: Exhibits superior adhesion as well as tear resistance and durability when compared with general-purpose tape. It is designed to withstand the harshest conditions and long-term usage.
- Applications: Designed for demanding industrial settings and applications that require the highest level of performance, like the HVAC system, maritime applications and construction.
Advantages of Aluminum Foil Tape
Aluminum foil tape has the following unique advantages over ordinary tape:
- High thermal conductivity: Aluminum foil tape is able to transmit heat and spread it across the surface it is bonded. It is ideal for situations where heat dissipation is required.
- Good barrier properties: This tape can effectively block the infiltration of outside substances like water vapor, oxygen as well as light and odor which aids in maintaining the security of the internal environment.
- Strong mechanical properties: Aluminum foil tape is distinguished by its characteristics of tear resistance, resistance to pressure and heat resistance. This can be used in extreme temperatures and high temperature conditions, which ensures a good bonding effects.
- High plasticity: Aluminum foil tape can adapt to the bonding needs of various curved surfaces and angles, ensuring strong bonding and not easy to age and fall off.
- Corrosion resistance: It’s able to withstand the erosion caused by chemicals like alkalis and acids, and is stable in harsh industrial environments.
- Fireproof performance: Aluminum foil tape is a good heat-insulation and smoke isolation that reduces the chance of burning.
- Excellent insulation performance: Usually has good electrical insulation performance and is suitable for electromagnetic shielding places.
These advantages make aluminum foil tape a popular choice in various areas, including automotive, electronics, construction, and packaging.
How to choose the type of aluminum foil tape according to the application?
- Construction and insulation applications
In the construction industry, if required to seal pipe insulation, and connection, then aluminum foil tape that has high temperature resistance as well as good moisture resistance is recommended. The tape must be able to withstand moisture and chemical corrosion, while retaining good bonding strength.
- Electronic product manufacturing
To manufacture electronic products specifically the heat conduction and shielding of circuit boards and circuit boards, aluminum foil tapes that possess outstanding thermal and electrical conductivity must be chosen. Additionally the tapes must be strong in tensile resistance as well as abrasion resistance that can withstand the physical strains of electronic components during manufacturing and usage.
- Automobile manufacturing and repair
In the area of automotive production, aluminum foil tapes are utilized as sound insulation and heat insulation materials and it is important to select a tape that is able to stand up to high temperatures and abrasions within the vehicle. If utilized for repairs to vehicles such as vehicle repair, the tape’s fast repair capability and simple operation properties may have to be taken into consideration.
- Special application requirements
In the area of automotive production, aluminum foil tapes are utilized as sound insulation and heat insulation materials and it is important to select a tape that is able to stand up to high temperatures and abrasions within the vehicle. If utilized for repairs to vehicles such as vehicle repair, the tape’s fast repair capability and simple operation properties may have to be taken into consideration.
When selecting aluminum foil tape, exact needs of the application need to be considered carefully, such as the mechanical properties required as well as the environment conditions (such as humidity, temperature or chemical exposure) and whether there are any specific electrical performance specifications. The correct match between the type of tape and application will ensure maximum performance and long-term durability.
